Solutions to STOP: 0x000000D1 Error (STOP 0xD1, Blue Screen Of Death, BSOD)

When STOP: 0x000000D1 Occurs

STOP: 0x000000D1 message on the blue screen is a critical warning sign that appears when Windows shuts down because of an unrecoverable error to prevent damage to your computer. Over time, 0x000000D1 may become more and more frequent, resulting in system corruption. That is why STOP: 0x000000D1 should be resolved as soon as possible.

However, 0x000000D1 error is not a reason to pay from $200 to $500 or even more to PC repair services for routine things you could perform your own at little or no cost. We hope the information below will help you remove 0x000000D1 error from your computer and save your money for something really worth that amount.

If you are not a computer expert use the following first-aid solutions:

If you can enter Windows (at least in Safe Mode):

  • Free Download 0x000000D1 Repair Program.0x000000D1 solution: Reimage Download
    Reimage detects and fixes a wide range of Windows problems, including 0x000000D1 and other blue screen errors, freezes, system file and registry damage, system and hardware instability, viruses, trojans and other problems. Reimage is the only tool that not just detects and removes viruses but also reverses the damage done to the system by a virus. Reimage is the only tool widely used by PC technicians to fix Windows errors.
  • Download the program, install and launch it.
  • Let the program scan your computer and repair the errors.

If you cannot enter Windows because of 0x000000d1 during bootup or logon:

  • Use this 0x000000d1 Repair Tool.0x000000d1 solution
    Spotmau BootSuite 2012 is designed specifically to boot unbootable computers and recover Windows, fix blue screen errors, corrupt registry, partition table, damaged system files and other Windows problems, including security issues.
  • Follow the simple instruction.
  • Enter your crashed system and let the utility recover Windows and fix the errors to prevent problems in future

In the unlikely case that STOP: 0x000000D1 remains look through the list of solutions below.

What causes STOP: 0x000000D1?

STOP: 0x000000D1 points to a critical problem with Windows system drivers. This problem is often caused by damaged or faulty Windows drivers (.sys files), malware (trojans, viruses, rootkits) or the damage it has done to your system files (in most cases, these are system drivers, the files with .sys extenstion), driver conflicts or incompatibilities, problems in the registry, like invalid references to specific drivers or damage. If you are not a computer expert use the first-aid solutions suggested on this page.

STOP: 0x000000D1 Solutions

STOP: 0x000000D1 Explanation

As a rule, STOP 0X000000D1 error message looks like this: STOP 0X000000D1 DRIVER_IRQL_NOT_LESS_OR_EQUAL Additionally, certain driver names can be mentioned pointing to the specific cause of 0X000000D1 error.

STOP: 0x000000D1 in Windows 2000 at Shutdown, Outdated Logitech MouseWare

You may get the follwoing STOP error message when you shut down a computer running Windows 2000:

STOP 0x000000D1, (0x0000002b, 0x00000002, 0x00000000, 0xEEEE1b01) IRQL_NOT_LESS_OR_EQUAL Kbdclass.sys. After that the computer restarts. If you use a Logitech mouse, STOP 0x000000D1 may occur because of the outdated version Logitech MouseWare, specifically versions 9.10 and 9.24. To resolve STOP 0x000000D1, remove the current version of Logitech MouseWare and update to the latest version.

STOP: 0x000000D1 on Windows XP Service Pack 2-based portable computer

You may get the following STOP: 0x000000D1 error message when you switch power modes from AC (utility) to DC (battery) on a Windows XP SP2-based portable computer with an Intel Pentium M (Centrino) mobile processor:

STOP 0x000000D1 (0x0000000C, 0x00000002, 0x00000000, 0xF8E26A89) gv3.sys - Address F8E26A89 base at F8E26000, Datestamp 3dd991eb

STOP 0x000000D1 may be caused by a force-installed Gv3.sys processor driver (for example, by mistake by an OEM driver utility installation program) Gv3.sys was used Windows XP and Windows XP SP1, but now it is obsolete. Windows XP SP2 requires Intelppm.sys processor driver that replaced Gv3.sys. To resolve STOP 0x000000D1, you’ll have to set the correct driver as your processor driver.

Occasional STOP: 0x000000D1 When Resuming from Standby

STOP: 0x000000D1 may occur when your computer is resuming from standby if all of the following are true:

  • you use Windows XP Service Pack 2 (SP2) on your computer
  • you are running the Sygate Personal Firewall on your computer
  • before resuming your computer remains on standby for a long time.

The Microsoft corporation does not provide support for 3rd party products, so you’ll have to contact Sygate for updates or request technical support on STOP: 0x000000D1 issue. Removing Sygate Personal Firewall is another workaround for STOP: 0x000000D1 error that you can use at your own risk because it makes your computer more vulnerable to malicious attacks. However, this is not a recommended solution. If you decide to remove Sygate Personal Firewall make sure you enable the Windows Firewall program or install a different third-party firewall program.

oxooooooD1 when reading data in a loop from a USB-Serial device on a Windows 7-based computer

This example of the error occurs because synchronization problem in a code path where it completes a IRP while another is trying to process it. Microsoft offers the following workarounds:

Workarounds:

  • Using the UsbSer source code, you can find it in the Windows Driver Kit (WDK).
  • Opt for WinUsb/UMDF.
  • Use Application level timeouts instead of COMMTIMEOUTS in your device

STOP: 0x000000D1 at shutdown with multiple USB devices

You may get STOP: 0x000000D1 error message during shutdown if you have one or several USB devices connected to your computer. This happens when the transfer descriptor is not fout in the list by OHCI endpoint. Microsoft confirmed that the this is the problem of a Windows system file. Installing the latest service pack should resolve STOP: 0x000000D1. Also, a supported hotfix for usbohci.sys file is available from Microsoft (kb 317326).

STOP 0x000000D1 on Windows Server 2003-based computer and Afd.sys file

If you got STOP 0x000000D1 error on Windows Server 2003-based computer and Afd.sys in mentioned in the error message, install the latest service pack for Windows Server 2003. Microsoft confirmed that the this is the problem of a Windows system file.

STOP 0x000000D1 When Unplugging Network Cable on Windows Vista-based computer

You may receive STOP 0x000000D1 you unplug the network cable or when your wireless network status is changing. The problem occurs because the Windows Filtering Platform (WFP) assumes that the IP interface is always available when a packet injection is in process, but the TCP/IP stack removes the IP interface when the network status changes and IP interface becomes unavailable.

Microsoft confirmed that the this is the problem of a Windows system file and provided a hotfix. (Note: the hotfix will fix only this particular case of STOP 0x000000D1 and is not applicable for other 0x000000D1 cases!)

Hotfixes for 0x000000D1

Very often, 0x000000D1 can be resolved with the help of hotfixes provided by Microsoft. A hotfix is issued when Microsoft finds that a certain Windows files has an error that prevents the system from working properly and causes it to crash with a specific error code.

Attention! Each hotfix is designed to fix only one specific case of 0xD1. It will not fix any other cases of code D1.

The software we recommened on this page autmatically repairs all of the issues that require a hotfix because it replaces all faulty, damaged or outdated system files with good files.

STOP: 0x000000D1 in Windows XP at Shutdown

You may get the following 0x000000D1 error message when you attempt to shut down WIndows XP: STOP 0x000000D1(parameter1, parameter2, parameter3, parameter4) DRIVER_IRQL_NOT_LESS_OR_EQUAL

HTTP.SYS

STOP 0x000000D1 may be caused by certain combinations of host firewall software and network adapter drivers. Microsoft fixed the problem in Http.sys file, the following version is available for download:

  • File name Http.sys
  • File version 5.1.2600.2869
  • File size 262,656
  • Date 17-Mar-2006
  • Time 01:08
  • Platform x86
  • SP requirement SP2
  • Service branch SP2QFE

STOP 0x000000D1 on a Windows Server 2003-based Computer

STOP 0x000000D1 Driver_IRQL_Not_Less_Or_Equal message may occur on a Windows Server 2003-based Computer under the following conditions:

  • You are using the Storport.sys storage driver
  • You have third-party enterprise storage management software installed.

STOP 0x000000D1 error occurs because Windows Server 2003 incorrectly processes the Startlo routine in Storport.sys. Microsoft confirmed that the this is the problem of a Windows system file and provided a hotfix. (Note: the hotfix will fix only this particular case of STOP 0x000000D1 and is not applicable for other 0x000000D1 cases!)

  • Date 15-Oct-2003
  • Time 18:15
  • Version 5.2.3790.83
  • Size 29,696
  • File name Wmspatcha.dll
  • Platform IA-64

  • Date 15-Oct-2003
  • Time 17:19
  • Version 5.2.3790.92
  • Size 248,320
  • File name Storport.sys
  • Platform IA-64

  • Date 15-Oct-2003
  • Time 20:19
  • Version 5.2.3790.92
  • Size 71,168
  • File name Storport.sys
  • Platform x86

Usng Storport.sys driver to manage storage devices in Windows Server 2008, in Windows Vista, in Windows 7 or in Windows Server 2008 R2

This case of 0x000000D1 is much similar to the above one. You get the bugcheck when You install some high-performance storage devices, such a host-based RAID or a fiber-channel adapter, managed with the help of Storport.sys on the above mentioned systems.

Storport.sys uses a signed value as the index of the debug log list. At the point when the value exceeds the maximum positive value, it starts to use negative index to query debug log entries. This results in memory access vilation as invalid memory is accessed, which causes the bugcheck message.

Microsoft confirmed that the this is the problem of a Windows system file (Storport.sys driver). A supported hotfix is available (see kb 983554).

STOP 0x000000D1 when uninstalling or unloading the driver for a multifunction USB device

You may get STOP 0x000000D1 on a Windows XP-based computer when you uninstall or unload the driver for a multifunction USB device installed on your computer and the driver implements the USB selective suspend features. STOP 0x000000D1 is caused by the USB composite class driver (Usbccgp.sys) which cannot complete the pending USB Idle-Notification I/O request packets already submitted by child device drivers. Later when child device driver is uploaded and but the pending I/O request packets are canceled the crash with STOP 0x000000D1 occurs. Microsoft confirmed that the this is the problem of a Windows system file and provided a hotfix. (Note: the hotfix will fix only this particular case of STOP 0x000000D1 and is not applicable for other 0x000000D1 cases!)

Windows XP SP3

  • File name Usbccgp.sys
  • File version 5.1.2600.5585
  • File size 32,384
  • Date 22-Apr-2008
  • Time 13:09
  • Platform x86

Windows XP SP2

  • File name Usbccgp.sys
  • File version 5.1.2600.3356
  • File size 32,384
  • Date 22-Apr-2008
  • Time 09:12
  • Platform x86

Accessing other than a PCI device in Windows 7

Microsot has confirmed that the BSOD is caused by an error in the Acpi.sys system driver. A non-PCI device should be regarded as a child of the PCI bus. The faulty driver causes it to be vewed by the system as a PCI device. As a result, the device is unable to work correctly when accessed by the OS. The issue with Acpi.sys driver is fixed in Service Pack 1 for Windows 7.

Resuming Windows 7 from hibernation

Error xD1 may occur when you resume a PC with a 1394 device attachd from sleep mode. Microsoft confirmed that the this is the problem of a Windows system file. Hotfixes for the following files are available: 1394bus.sys, 1394ohci.sys, Ohci1394.sys.

Connecting a USB composite device on a Windows 7 based computer.

Microsoft confirmed that the this is the problem of a Windows system file (an error in the composite device driver Usbccgp.sys).

Technical information:

This happens when Windows expects a D2 power request from a the callback function of a client driver, but it sends a D3 power request. As a result, the following behavior takes place, causing access violation, which, eventually, causes the crash:

  • the idle IRP is completed and freed when the completion routine is run
  • the freed idle IRP is accessed by Usbccgp.sys after the callback function returns
  • PC crashes

A supported hotfix is available (see kb 2615763).

0X000000D1 in rdbss!RxTimerDispatch in Windows 7 Service Pack 1

Microsoft confirmed that the this is the problem of a Windows system file. A supported hotfix is available (see kb 2895237).

0X000000D1 when transferring USB data and selecting USB interface

Error 0x000000D1 may occur in Windows 7 or Windows Server 2008 R2 when you initialize communication with a Composite USB device, with multiple logical USB devices implemented as children of one physical (parent) USB device

In a Composite USB device, multiple logical USB devices are set up as children of one physical (parent) USB device. The following scenarion takes palce, according to the explanation from the Microsoft:

  • one function driver chooses the Interface for its function
  • it removes the pipes associated with the previous Interface from the pipe list of the device
  • the pipe list is left in an inconsistent state for a short period of time because this procedure is not protected by a lock
  • at the same time, another function driver is making transfers to or from one of its pipes.
  • usbport.sys starts to processes a new USB transfer
  • in order to to validate the USB pipe, it scans the device’s pipe list for the target of the transfer
  • usbport.sys finds that the pipe was removed from the list
  • usbport.sys dereferences the NULL link pointer from the pipe being removed
  • system crashes with the code D1.

Microsoft confirmed that the this is the problem of a Windows system file (Host Controller Port driver usbport.sys).

Installing TDI drivers in Windows 7, Windows Server 2008 or Windows Server 2008 R2

0X000000D1 error message lising Afd.sys file may occur after installing Transport Driver Interface drivers on the above mentioned systems.

This happens because endpoint structure of Transport Driver Interface is created and populated when a WinSock application makes an attempt to bind a socket. In this situation, a network interrupt occurs before the endpoint structure of Transport Driver Interface is initialized. As a result, the Afd.sys file tries to access uninitiated data structure, causing the PC to crash.

Microsoft confirmed that the this is the problem of a Windows system file (Afd.sys driver). A supported hotfix is available (see kb 2781571).

OxD1 at Startup in Win XP

This error occurs because of a race condition caused by power management code in Acpi.sys file (system driver). To be more specific, this happens when your computer’s BIOS has multiple tables and at least two of them contain power resources. This makes Acpi.sys access nodes that are not initialized. This situation creates the race condition.

Microsoft confirmed that the this is the problem of a Windows system file (Acpi.sys driver). A supported hotfix is available (see kb 839876).

0X000000D1 when running a telephony application that uses the RAS PPPoE driver in Windows 7

The error happens on a PC running a 32-bit version of Windows 7 when you run a telephony application that uses the Remote Access Service (RAS) Point-to-Point Protocol over Ethernet (PPPoE) driver Rasppoe.sys. This dtiver attempst to do an operation not permitted during the Deferred Procedure Call (DPC) processing, whuch causes the crash.

Microsoft confirmed that the this is the problem of a Windows system file (Remote Access Service Point-to-Point Protocol over Ethernet driver Rasppoe.sys). A supported hotfix is available (see kb 2495313).

What if I Still Cannot Fix STOP 0X000000D1?

If STOP 0X000000D1 still remains on your computer and you cannot find neither cause nor solution, use this last resort system fix:

This tool is widely used by PC technicians to automatically solve Windows problems and software related blue screen errors (such as STOP 0X000000D1). Reimage is the only tool that fixes the whole system (not just the registry or malware) and even reverses the damage from a virus with the help or a large database or healthy replacement files. In most simple terms, the effect from Reimage fix is the same as having a fresh, healthy installation of Windows and preserving all your files, programs, settings and profiles, which had never been possible before.

We hope these suggestions helped you resolve STOP 0x000000D1 error.
